This is some of the previous quads / multirotors / birds I’ve had in the past. Probably a cool way of seeing what we flew previously!
QuadRevo Rage X
I have two three two “three” QuadRevo Rage X’s… they are meant for racing. The original ideal was to have multiple identical setups so that in the event of destroying one in a race I could easily swap it out for another. Due to the evolving nature of this hobby I have realized that it’s really not feasible to keep all of them up to date with the latest technology. Although this presented a unexpected benefit though; I can keep them similar and change little things and I’ll know if there really is a difference or if it’s just “hype”.
I am trying to do my best to keep this page updated with the current components. I no longer provide the CLI Dump because honestly I’m barely adjusting the tune now days.
QuadRevo 5″ Rage X Revolt
Frame: QuadRevo 5″ Rage X (pre-production)
Brushless Motors: Emax RS2205-2600KV
Electronic Speed Controllers: Aikon SEFM 30A BLHeli_S
PDB: QuadRevo PowerOSD Pro 2
Flight Controller: RaceFlight Revolt
Firmware: RaceFlight
Propellers: DALprop T5045C Cyclone Three Blade Prop
Flight Camera: RunCam Swift (settings)
Video Transmitter: TBS Unify Pro 5.8 GHz HV Race
Antenna: Foxeer 5.8 GHz Stubby RHCP
Receiver: FrSky XSR
Controller: Taranis Plus
QuadRevo 5″ Rage X Hyperlite
Frame: QuadRevo 5″ Rage X (pre-production)
Brushless Motors: Emax RS2205-2600KV
Electronic Speed Controllers: Aikon SEFM 30A BLHeli_S
PDB: QuadRevo PowerOSD Pro
Flight Controller: Hyperlite F4
Firmware: RaceFlight
Propellers: DALprop T5045C Cyclone Three Blade Prop
Flight Camera: RunCam Swift (settings)
Video Transmitter: TBS Unify Pro 5.8 GHz HV Race
Antenna: Foxeer 5.8 GHz Stubby RHCP
Receiver: FrSky XSR
Controller: Taranis Plus
QuadRevo 4″ Rage X
Frame: QuadRevo 4″ Rage X (pre-production)
Brushless Motors: Emax RS2205-2600KV
Electronic Speed Controllers: DYS XSD 20A BLheli_S
PDB: QuadRevo PowerOSD Pro
Flight Controller: Lumenier LUX
Firmware: Betaflight 3.0.1
Propellers: DALprop T5045BN
Flight Camera: HS117 (settings)
Video Transmitter: FX668T 5.8 GHz 40 Channel 200mW
Antenna: Foxeer 5.8 GHz Stubby RHCP
Receiver: FrSky XSR
Controller: Taranis Plus
Batteries (they share batteries):
Tattu 1050 4S 75c
CNHL G+ 13000mAh 70c
Turnigy Graphene 4S 1300mah
Turnigy Bolt 4S 1300mah
QuadRevo 210
The QuadRevo Rage 210 is a 4mm bottom plate 3K Twill weave carbon fiber. This was my second frame from QuadRevo and a true beast. Capable of running 5″ props it has plenty of power to go around. This was the quad I took raced at the California Cup Finals in Southern California. Despite many people at the races utilizing X frames, I was still able to take home 2nd place.
Since it’s original build back in September, very little has changed, replaced motors/esc’s when needed. Shortened the stack a bit, but the overall components have been identical since it’s first build.
Frame: QuadRevo 210
Brushless Motors: Lumineer RX2206-11 2350kv
Electronic Speed Controllers: FVT LittleBee 30amp
PDB: QuadRevo PowerOSD Pro
Flight Controller: Sparky v1.1
Propellers: GemFan Tri-Blades 5045
Flight Camera: HS1177
Video Transmitter: FX799T (200mw)
Antenna: VAS 5.8 GHz RHCP DuraSpec
Receiver: FrSky X4R
Controller: Taranis Plus
Batteries:
Tattu 1050 4S 75c
Multistar RaceSpec 1400
Airblade 130X
Here is a list of the various AirBladeUAV quads.
The Emax motors feel a bit more peppy but it’s not a HUGE difference imo. Plus most of the time you are flying a 130 you are flying it in tight conditions so the extra power may not be utilized much.
Airblade 130 X-Racer – Emax
Frame – AirBladeX 130 X-Racer 3K Carbon Fiber Frame
Flight Controller – SirinFPV Flight Controller
ESCs – DYS XS20A ESC – BLHeli_S
Motors – EMAX RS1306 4000 KV RaceSpec Brushless Motor
Propellers – RotorX RX3040 Prop
FPV Camera – RunCam Owl
Antenna – Foxeer 5.8 GHz STUBBY RHCP Antenna
Receiver – FrSky XSR CPPM/S.Bus Receiver
Airblade 130 X-Racer – DYS
Frame – AirBladeX 130 X-Racer 3K Carbon Fiber Frame
Flight Controller – SirinFPV Flight Controller
ESCs – DYS XS20A ESC – BLHeli_S
Motors – DYS BX1306 4000kv Brushless Motor
Propellers – RotorX RX3040 Prop
FPV Camera – “520” Camera
Antenna – Foxeer 5.8 GHz STUBBY RHCP Antenna
Receiver – FrSky XSR CPPM/S.Bus Receiver
Airblade Creampuff
Frame – AirBladeUAV Creampuff
Flight Controller – FuriousFPV PIKO BLX
ESCs – DYS XM10
Motors – RotorX 1105B 6500kV
Propellers – RotorX RX2535
FPV Camera / VTX – Eachine TX03
Receiver – FrSky XM
Batteries:
Tattu 850 4S 75c
Airblade Premium 850mah 4S 75c LiHV
Turnigy Nano-Tech 850 4S 45-90C
Airblade Creampuff
FloRotors 130
The small scale racing quad of choice for me is the FloRotors 130. It’s falls just under the FAA registrations size and is really a beefy frame… probably more than what is needed. I opted for many “full size” components so that I am able to get the best possible performance with little compromise.
AUW: 246g
Frame: FloRotors 130
Motors: DYS BX1306 4000kV
ESC: DYS XM20a
Props: GemFan 3″ TriBlades
Flight Controller: Lumenier Lux
Firmware: Betaflight 2.7.1
VTX: FX688T-2 (200mw tx)
Camera: Micro 600TVL (170deg)
Receiver: FrSky XSR
Battery: Turnigy Bolt 850 3S
